XJF800 LED Epi-fluorescent microscope is used for fluorescence microscopy and transmitted field observation. It is equipped with no magnification sphero-chromatic aberration infinity plan achromatic fluorescent objectives and wide field eyepieces, has clear picture and wide view field. The transmitted and epi-fluorescent illumination light source are high power & brightness LED, but power consumption is lower and use life longer, very good radiating heat effect. Safely and comfortably using the instrument, the cost of use and maintenance are lower. It is the ideal instrument in biology, cytology, oncology, genetics, immunology etc. It also can be used in scientific research, universities, medical treatment, epidemic prevention etc.
Category: Fluorescence Microscope
Transmitted light: 3W high brightness white LED, Brightness adjustable
Reflected light: 5W high brightness LED Brightness adjustable
Infinity Optical System F=200mm
Seidentopf Trinocular Head, 30°inclined (55-75mm)
360° rotatable, diopter adjustable.
WF10X/22mm with reticule, 0.10mm/Divide
Plan Achromatic Objective 4X/0.10 WD=19.8mm
Plan Achromatic Objective 10X/0.25 WD=5.0mm
Plan Achromatic Objective 40X/0.85 WD=0.42mm
Plan Achromatic Objective 100X/1.25 WD=0.36mm
Plan Achromatic Objective 60X/0.80 WD=0.46mm
Plan Achromatic Fluorescent Objective 10X/0.35 WD=2.37mm
Double layers mechanical stage
Stage size: 210mm × 140mm
Moving range: 75mm × 50mm
Abbe condenser NA.1.25 Rack & pinion adjustable
Coaxial coarse/fine focus system, with tension adjustable and limit stopper, minimum division of fine focusing: 2μm.
5W high brightness LED Enable selecting monochromatic or biochromatic LED for light source
B Excitation LED Filter (410nm~490nm)
G Excitation LED Filter (475nm~550nm)
UV Excitation LED Filter (320nm~380nm)
V Excitation LED Filter (380nm~415nm)
Collector for LED illumination and integrated field diaphragm
3W high brightness white LED，adjustable brightness
Note: "●"In Table Is Standard outfits, "○" Is Optional Accessories.
Pack: 1 carton, G.W.: 15.6KGS, Meas.49.5*65*35CM
